Note:The USB interface is only powering for this wifi repeater, It is not a TV adapter.If your TV has a Lan port or your TV can receive Wifi, this item will be compatible with your TV.
Brand Name : PIXLINK
Model Number : LV-UE01
Universal TV card is designed for the device via the network cable Internet access wireless Internet access born artifact. With it your home television network set-top boxes. IP cameras through the network cable Internet appliances, wireless internet can achieve. You no longer have to worry about how the wiring problem.
After plug in the USB power supply, press the product WPS button, and then click on the button WPS wireless router, you can connect to the network, the access network by cable to the Ethernet port of the TV, the TV will be able to connect the Internet. You can also set up the network connection through the WEB by scanning the signal input corresponding WIFI password, keep it on it.
Features:
100% Brand New and High Quality
Light weight and easy to use
WPS Button
Operation as a repeater
Compatible with Any Smart TV with RJ45 Port
Netowrk cable include
Wifi Standard technology :802.11 b/g/n
Wifi frequency :2.4GHz
Dimension : 80x 27 x13mm
Weight : 16g
Specifications :
Wireless |
Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Data Rate |
11n: 300Mbps
11g: 54Mbps
11b: 11Mbps
|
Frequency Range |
2.4-2.4835GHz |
Wireless Transmit Power |
<20dBm |
Receive Sensitivity |
150M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER |
Operation Mode |
Repeater / AP |
Wireless Security |
64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES) |
System Requirements |
Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS |
Hardware |
Interfaces |
1 x 10/100Mbps LAN/WAN Port
1 x USB 2.0 Port
|
Button |
WPS Button
Reset Button
|
Antenna |
2 x 3dBi Build-in omni-directional Antenna |
Power Supply |
100-200V AC 50/60Hz |
USB Power Output |
USB 5v,500mA |
Others |
Operating Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
Relative Humidity |
10% ~ 90%, Non-condensing |
Storage Humidity |
5%~95%, Non-condensing |
Package Include:
1 x USB Wifi TV Adapter
1 x User Manual
1 x Network Cable
